Cable With Excellent Mechanical And Environmental Properties
1.Selected high quality optical fiber ensure the optical fiber cable have excellent transmission properties.
2.The unique fiber excess length control method provides the cable with excellent mechanical and environmental properties.
3.Very strict material and manufacturing control guarantees the cable can work stably for more than 30 years.
4.Total cross-section water-resistant structure makes cable have excellent properties of moisture resistance.
5.Special jelly filled in the loose tube provides the fibers with critical protection.
6.The out PE sheath provides good anti-UV radiation performance.
| Packaging Details: | Packed on fumigated wooden Drum suitable for long distance shipment. |
|---|---|
| Delivery Detail: | 15 Days |
| Fiber number | Max. fiber number per tube | Loose tube | Filler rod | Sheath thickness (nominal*) | Messenger wire | Outer diameter (nominal**) | Weight (approx.) |
| mm | (mm) | mm | kg/km | ||||
| 6 | 6 | 1 | 4 | 1.8 | 1.0*7 | 9.1*17.0 | 127 |
| 12 | 6 | 2 | 3 | 1.8 | 1.0*7 | 9.1*17.0 | 128 |
| 24 | 6 | 4 | 1 | 1.8 | 1.0*7 | 9.1*17.0 | 129 |
| 36 | 6 | 6 | 0 | 1.8 | 1.0*7 | 9.7*17.1 | 138 |
| 48 | 12 | 5 | 0 | 1.8 | 1.0*7 | 10.6*18.5 | 154 |
| 72 | 12 | 6 | 0 | 1.8 | 1.0*7 | 11.4*19.3 | 168 |
| 96 | 12 | 8 | 0 | 1.8 | 1.0*7 | 12.1*20.0 | 209 |
| 144 | 12 | 12 | 0 | 1.8 | 1.0*7 | 14.9*22.8 | 240 |
2. The fiber optic cable Drawing
FAQ
Q1: Where is your factory ?
A1: Our factory is located in Hangzhou City, Zhejiang Province, China.
Q2: How long has your company been doing this?
A2: More than 20 years.We are not only produce fiber optical cable but also produce optical fiber and related tools .
Q3: Can provide free sample to us?
A3: Yes,sample cable below 20 m can be provided by free ,but you need pay the freight fee.
Q4: Can you produce cable as our requirements?
A5: Of course .We can supply different types of products according to your requirements with reasonable prices .
Our Services
More product for you to choose:
Aerial optic fiber cables, Duct optic fiber cables, Direct burial optic fiber cables, Underground optic fiber cables; ADSS all dielectric self-supporting optic fiber cables,FRP strength member optic fiber cables, etc.
Packaging & Shipping
Inner packed in fumigated wooden drum, and outer covered by polyethylene sheet,then sealed by strong wooden battens;or any other package you see from the market we can make for u as well,any OEM order is welcome.
